Manufacturer type designation

E15

Drive unit

Electric

Operator type

Walkie

Rated capacity

kg

1500

Load centre distance

mm

600

Wheel base

mm

1284/1354

Service weight (with battery)

kg

275

Tyres type

PU

Tyre size, front

mm

80*58

Tyre size, rear

mm

252*67

Wheels number front/rear

4/1

Lift height

mm

110

Height of tiller in drive position min./max.

mm

750/1050

Lowered height(fork)

mm

85

Overall length (platform fold/unfold)

mm

1626/1696

Overall width

mm

560/685

Fork dimensions

mm

1150/1200*160*44

Width across forks

mm

560/685

Min. Aisle width 1000x1200 (platform fold)

mm

2058

Min. Aisle width 800x1200 (platform fold)

mm

2017

Turning radius (platform unfold)

mm

1510/1590

Travel speed, loaded/unloaded

km/h

3/3.5

Lift speed, loaded/unloaded

mm/s

56/60

Lowering speed, laden / unladen

mm/s

57/59

Max. gradient performance, laden / unladen

%

5/7

Service brake

Electro Magnetic

Drive motor rating S260 min.

kw

DC0.6

Lift motor rating at S315%

kw

DC0.8

Battery acc. To din 43531/35/36, a, b, c no

Maintenancel-free

Battery voltage, nominal capacity

V/Ah

24/70

Battery weight

Lb.

50
